12 Cubic Meter Water Sprinkler Truck Product Introduction

Based on the analysis of the provided PDF file, this document details the specifications, configuration, and features of a 12 cubic meter water sprinkler truck, a versatile vehicle designed for road cleaning, irrigation, dust suppression, and water transportation.

1. Product Overview

The sprinkler truck, also known as a spray truck or multi-purpose sprinkler, is suitable for various applications including:

• Washing roads and streets
• Irrigating trees, green belts, and lawns
• Dust suppression at industrial, mining, and construction sites
• Water transportation

Common models include sanitation sprinklers, multi-purpose sprinklers, and landscaping sprinklers.

2. Standard Equipment and Core Components

The vehicle comes with a comprehensive spraying system:

• Spraying Functions: Front flush (duckbill), rear sprinkling, side spray, and a rear-mounted landscaping water cannon (360° rotatable, adjustable for column, mist, direct flow, and various rain patterns).
• Core Water Pump: High-quality, high-power, self-priming, self-draining dedicated pump capable of drawing water from rivers or ponds. Equipped with PTO, debris filter, firefighting connection, and gravity ball valve system.
• Work Platform: Rear-mounted punching platform for enhanced load-bearing capacity, facilitating operation of the water cannon.

3. Detailed Chassis and Superstructure Configuration

4. Main Technical Parameters

5. Product Function Display

According to the document, the sprinkler truck features the following spraying modes:

• Front Flush (Duckbill): For powerful road surface cleaning.
• Rear Sprinkling: For even water distribution on road surfaces.
• Side Spray: For irrigation of green belts or roadside areas.
• Water Cannon (Anti-aircraft gun style): For long-distance, high-range spraying, adjustable to column or mist.
• High-position Shower: For specific landscaping tasks.

6. Manufacturing Process Highlights

• Tank Welding: Automatic welding using a US Lincoln welding machine ensures beautiful, pore-free, and leak-proof welds.
• Surface Treatment: The tank undergoes sandblasting/shot blasting to remove welding slag and impurities, followed by anti-rust painting for longevity.
• Pipeline System: Uses seamless steel pipes with anti-rust treatment.
• Modular Design: Side guards, rear bumper, and fenders are bolted for easy disassembly and maintenance.
• Subframe: Edging treatment protects the subframe and prevents bottom plate tearing.

7. Optional Additional Configurations (Non-Standard)

As per the document, optional accessories include:

• Cylinder
• Toolbox
• Pneumatic Valve
• Arrow Light

This 12 cubic meter water sprinkler truck is well-designed, fully equipped, and built with robust manufacturing processes. It is a versatile and efficient specialized vehicle suitable for urban sanitation, landscaping, and construction projects.
